iFDC
Category Access Control
Brand IDTECK
Model iFDC
CPU 32 bit (ARM Coretex A8) Microprocessor
OS Embedded Linux
Memory 512MByte Flash / 256MByte DDR2 SDRAM
ID User Up to 100,000 Users
Event Buffer Up to 100,000 Events
Web Server Embedded Web Server
(Controls up to 4 Doors when Operated via Web Browser)
Power Power Input / Current DC 12V / Max 600mA
PoE PoE+(IEEE 802.3at), Max 30W
Reader Port 4 EA (Available Up to 8 Readers with Expansion Board ERIO)
- Default: 26/34 Bit Wiegand, 4/8 Bit Burst for PIN
- Programmable Wiegand Format to suit Customer Request (Up to 53Bit)
LED / Buzzer Control 4 EA
Communication Ethernet / RS232 / RS485 (Max. 32ch.)
Communication Speed Ethernet  10/100Mbps
Serial 57,600 bps (Default)
/ 9,600 bps / 19,200 bps / 38,400 bps / 115,200 bps (Selectable)
LED Indicator

39 LED Indicators
Input Port

8 EA (Selectable, 4-State Supervised Input)
1 EA (Tamper Switch Input Port)
(Up to 80 Inputs with ERIO, UIM, UOM)
Output Port 8 EA : 2 FORM-C Relay Output (COM, NO, NC) / DC 12V < 18V, Rating Max. 2A
(Up to 80 Outputs with ERIO, UIM, UOM)
Buzzer Piezo Buzzer
Operating Temperature 0°C to +65°C
Operating Humidity 10% to 90% relative humidity non-condensing
Dimension (W x H x T) 220mm x 145mm x 25mm
Weight 294g
Certification FCC, CE, KC, RoHS, UL
ERIO (Expansion Reader / Input / Output Board)
/ Required for Controlling 5<8 doors="" th="">
Reader                                       4 Reader Ports
LED / Buzzer Control 4 EA
Input Port 8 EA (Selectable, 4-State Supervised Input)
Output Port 8 EA : 2 FORM-C Relay Output (COM, NO, NC) / DC 12V < 18V, Rating Max. 2A
Dimension (W x H x T) 137mm x 169mm x 28mm (4.1” x 6.7” x 1.1”)
Weight 173 g
Model UIM
(Expansion Input Board)		 UOM
 (Expansion Output Board)
CPU 32 Bit Microprocessor
Input Port 16 EA : Input Type Selectable
(4-State Supervised Input)		 2 EA : Input Type Selectable
(4-State Supervised Input)
Output Port 2 EA :2 FORM C Relay Output (COM, NO, NC) 16 EA : 2 FORM C Relay Output (COM, NO, NC)
Communication   RS485  (Up to 4ea UIM and Up to 4ea UOM per 1 iFDC / iEDC )
LED Indicator 22 LED Indicators
Power / Current DC 12V / Max.200mA         DC 12V / Max. 450mA
Dimension (W x H x T) 157mm x 137mm x 16mm 157mm x 185mm x 16mm
Weight unit weight: 139.5g( 0.308lb) unit weight: 203g( 0.448lb)


* Time Schedule

Time Code 255
Time Interval 24

Holiday Code 255
Holiday 256
